TECHNICAL

1.  Max. operating pressure: 10.2/8.5 bar
2.  Type: 20/30
3.  Stroke: 65/65
4.  Output force S: 11500N/20mm
5.  Release pressure: 5.1 bar
6.  Output force D: 7700N/6.5bar
7.  Yoke: without (M 16x1.5)
11.  Port threads: M 16x1.5
12.  with fording ability: no
13.  Push-rod length: 250
14.  Thread length: 250
15.  Angle a: -135°
16.  Angle b: 0°
17.  Angle c: 0°
18.  Distance between bolts: 120.7
19.  Bolt threads: M 16x1.5
20.  Bolt lengths: 43
21.  Sealing: Disc
22.  Return-spring force: 250
23.  Over stroke: no
24.  Opposite: -
