TECHNICAL

Spring Portion Diameter [mm] 187 mm
Stroke (stroke of service/stroke of spring portion) [mm] 57/57
Has opposite handed version K047835N00
Service Portion Port(s) size M16x1,5
Spring Portion Port(s) size M16x1,5
Service Portion Type (Diaphragm size) 20
Spring Portion Type 24
Push rod end M16x1,5 (Y)
Push rod length (to yoke pin centre if fitted) [mm] 285 mm
Push rod thread length [mm] 290 mm

OE Nr :

REF Nr :
