OEM: 8160471, 08160471, 041017242, 08160467, 08160465, 41000229

Technical Sheet

Exhaust Connector Snap-on Connector
Heater Connection Type Bayonet (2 x O4,0 + 1 x O4,5)
Heater Voltage [volts] 24 Volt
Weight [Kg] 4.18 kg
Air Inlet port(s) size M22x1,5
Air Delivery port(s) size M22x1,5
With internal Silencer Yes
Purge control Reservoir; Port: M12x1,5
Safety valve pressure [bar] 17,0
Unloader cut-out pressure [bar] 12,5 +/-0,2
Unloader pressure control range [bar] 0,9 +0,7
